Kyocera AVX has introduced the CP2816 Series of integrated thin film (ITF) directional couplers, engineered to meet demanding requirements in VHF/UHF wireless communication systems. The new 7×4mm components combine high power handling with precision performance for mission-critical applications across defense, telecom, and automotive sectors.
High-Performance RF Coupling in Miniature Form
The CP2816 Series delivers 20W continuous power handling across a 225–750MHz operational bandwidth while maintaining exceptional signal integrity. Its compact LGA packaging features nickel terminations compatible with all standard soldering processes, enabling seamless integration into space-constrained designs. The couplers demonstrate outstanding temperature stability, functioning reliably from -40°C to +105°C environments.
Precision Engineering for Critical Systems
Key technical advantages include:
- Ultra-low insertion loss (<0.9dB)
- Tight coupling tolerance (±1.2dB option available)
- Consistent 50Ω impedance with 1.3 VSWR
- -14dB directivity for accurate signal sampling
These specifications make the components ideal for base station filters, tactical radio systems, and radar equipment where signal fidelity is paramount.
Ruggedized for Demanding Environments
Manufactured in ISO-9001 certified facilities with IATF 16949 compatibility, the couplers meet stringent quality requirements for:
- Military communications equipment
- Emergency response systems
- Automotive telematics
- Aerospace avionics
The RoHS-compliant design incorporates robust nickel terminations resistant to mechanical stress and thermal cycling.
Streamlining RF System Design
Available in tape-and-reel packaging with multiple coupling factor options (-10dB to -15dB), the CP2816 Series simplifies inventory management while providing design flexibility. Kyocera AVX’s proven thin film technology ensures high lot-to-lot consistency, reducing qualification overhead for manufacturers transitioning from discrete coupler solutions.
