The semiconductor industry is transitioning from traditional batch processing to advanced single-wafer ashing techniques to meet the demanding requirements of modern chip fabrication. This shift comes as compound semiconductors made from materials like silicon carbide and gallium nitride require more precise photoresist removal than standard silicon wafers.
Precision Processing for Diverse Semiconductor Materials
Unlike uniform 300mm silicon wafers, compound semiconductors vary between 100-200mm and demand superior process control. Microwave plasma ashing systems now offer manufacturers the ability to achieve high-temperature photoresist removal with exceptional uniformity while protecting sensitive underlying layers. Leading providers like PVA TePla have developed solutions that combine speed and precision for these specialized applications.
Microwave vs. RF Plasma: A Technological Leap
For decades, RF plasma dominated photoresist removal through physical bombardment processes. However, this approach lacks selectivity and risks damaging wafer surfaces. Modern microwave plasma systems using oxygen as the primary process gas provide targeted photoresist removal while preserving the integrity of delicate wafer structures. When oxygen alone proves insufficient, systems can incorporate fluorine chemistry (typically CF4) to address more complex material combinations.
Adapting to Advanced Material Challenges
The increasing complexity of semiconductor materials presents new challenges for ashing processes. Some wafer surfaces contain metals that oxidize undesirably during standard oxygen processing. For these applications, manufacturers have developed hybrid approaches using carefully controlled mixtures of hydrogen and oxygen gases at low pressures. These advanced techniques maintain the delicate balance between complete photoresist removal and substrate protection.
The Future of Wafer Processing
As semiconductor technology continues advancing, single-wafer microwave plasma ashing systems are becoming essential tools for next-generation chip fabrication. Their ability to handle diverse materials with precision and speed positions them as critical components in semiconductor manufacturing, particularly for compound semiconductors powering advanced electronics and power devices.
